P/N HDPL-HLINK12IN

12" Hyperlink

A 12" rigid coupler extension, that can be mounted to  (5) Bases and/or Knuckles.

P/N HDPL-KNK

Knuckle
Adaptable to the ball ends of all Posts and Hyperlinks to achieve maximum articulation. A strategic player in the Pop-Link™ system.

The Accessories

P/N HDPL-TPOST6IN-BK

6" Telescopic Post - Bracket Adaptable End

Telescoping post that may be positioned within a 6" range of travel, with an adapter on one end to mount most products in The Bracket Series.

P/N HDPL-TPOST8IN-BL

8" Telescopic Post - Ball End

Telescoping post that may be positioned within a 8" range of travel, with a ball end.

P/N PL-HDPL-DSTAND1

Demo Stand

A  stainless steel stand to which  you can mount a base from  The PL Series (PL-BASE)  and The HDPL Series (HDPL-BASE).   Ships with mounting hardware  for both bases (bases not included).

P/N HDPL-TPOST6IN-THD

6" Telescopic Post - Threaded End

Telescoping post that may be positioned within a 6" range of travel, with an M16X2 male threaded end.

P/N HDPL-TPOST8IN-BK

8" Telescopic Post - Bracket Adaptable End

Telescoping post that may be positioned within a 8" range of travel, with an adapter on one end to mount most products in The Bracket Series.

The hyperlinks

P/N HDPL-SPOST-THD

Standard Post - Threaded End

 A rigid (non-telescopic) mount post with an M16X2 male threaded end.

P/N HDPL-TPOST6IN-BL

6" Telescopic Post - Ball End

Telescoping post that may be positioned within a 6" range of travel, with a ball end.

P/N HDPL-SPOST-BK

Standard Post - Bracket Adaptable End

 A rigid (non-telescopic) mount post with an adapter on one end to mount most products in The Bracket Series.

P/N HDPL-HLINK9IN

9" Hyperlink

A 9" rigid coupler extension, that can be mounted to  (4) Bases and/or Knuckles.

The Essentials

P/N HDPL-TPOST2IN-BK

2" Telescopic Post - Bracket Adaptable End

Telescoping post that may be positioned within a 2" range of travel, with an adapter on one end to mount most products in The Bracket Series.

P/N HDPL-BALLBASE

Ball Base
The ball end of the HDPL-BALLBASE allows direct mounting to a HDPL-KNK or HDPL-BASE. The flat side allows mounting to  The Enclosure Series or your products, such as HMIs or panels.

P/N HDPL-TPOST2IN-BL

2" Telescopic Post - Ball End

Telescoping post that may be positioned within a 2" range of travel, with a ball end.

P/N HDPL-TPOST2IN-THD

2" Telescopic Post - Threaded End

Telescoping post that may be positioned within a 2" range of travel, with an M16X2 male threaded end.

P/N PL-HDPL-VB1

Vacuum Base

A built-in hand pump produces vacuum for holding with a rating of 70 pounds of holding force when mounted in a vertical position with the load in a down position. Recommended for temporary application.  Requires smooth mounting surface. Testing for “time to hold” is recommended prior to actual use.  Compatible with PL-BASE and HDPL-BASE.   Ships with stainless steel mounting hardware  for both bases (bases not included).

The HDPL Series provides all of the versatility as The PL Series, but can handle a heavier load.  All products in The HDPL Series are made from anodized 6061 aluminum with stainless steel fasteners.   The HDPL Series is compatible with most products in  The Bracket Series.


Select from individual parts in The HDPL Series to build your own mounting system, or choose a Kit which is an easy way to order the most commonly used, basic mounting systems. Click here to visit  The HDPL Series Kits.

P/N HDPL-TPOST8IN-THD

8" Telescopic Post - Threaded End

Telescoping post that may be positioned within a 8" range of travel, with an M16X2 male threaded end.

P/N HDPL-HLINK3IN

3" Hyperlink

A 3" rigid coupler extension, that can be mounted to  (2) Bases and/or Knuckles.

The posts

P/N HDPL-BASE

Base
The foundation of the Pop-Link™ System. It all starts here! Easily mounts to most aluminum extrusion.

The HDPL Series

P/N PL-HDPL-MAG1

Magnetic Base

A magnetic base to which a base from the  The PL Series (PL-BASE)  or The HDPL Series (HDPL-BASE) can be mounted.   Ships with mounting hardware  for both bases (bases not included).

Mounting

Made

Easy!

P/N HDPL-CS

Clamshell
The clamshell directly mounts to the HDPL-KNK or  HDPL-BASE. It has a .751"Ø through hole that acts as a sleeve to clamp down onto your specific application.

P/N HDPL-HLINK6IN

6" Hyperlink

A 6" rigid coupler extension, that can be mounted to  (3) Bases and/or Knuckles.

​Pop-Link Mounting Systems
